SVEZA Laser Standard

SVEZA Laser Standard

Birch throughout plywood specially designed for making die boards.

The product meets the specific requirements of the industry and comes with a choice of sizes and coating options for any type of die board.

The grade SVEZA Laser Premium features inner layers of the highest quality. Other parameters are the same in SVEZA Laser Standard and SVEZA Laser Premium.

Request for calculation
Properties Advantages Applications Apps
Properties
Specifications
Parameter Value
Panel sizes, length x width, mm (ft) 1525×1525 (5×5)
1220×1525 (4×5), 1250×1525 (4×5)
1525×1250 (5×4), 1525×1250 (5×4)
2440×1220 (8×4), 2500×1250 (8×4)
2500×1500 (8×5)
1525×3050 (5×10)
2130×1220
1830×1220
1525×2500
1525×2200
Notes 1. SVEZA Laser plywood can be made to the customer’s size specifications.
2. The length of a SVEZA Laser plywood sheet is measured along the grain of the face and back veneers.
Thickness, mm 3–12 ± 0.3
15–30 ± 0.2
Notes 1. SVEZA Puzzle plywood can be made to the customer’s specifications for thickness, number of plies, and tolerances.
2. Thickness variation across one panel does not exceed 2 mm.
Surface S2S: Sanded both sides
UV/UV: Coated with UV-cured material on both sides
F/F: Faced with melamine film
Raw
Overlaid with transparent melamine film
Grade B/BB, BB/BB, ВВ/СP
Glue MR (Interior)
Wear rating (Taber value) 350
Formaldehyde emission Е0.5
CARB & EPA on request
Moisture, % ≤10
* Manufactured to company standard STO 52654419-003-2024 “SVEZA Laser birch plywood. Standard specifications.”

Advantages

utp
Tight thickness tolerances
utp
Consistently flat sheet
utp
Laser-compatible glue
utp
Choice of coating options and colors

Applications

Manufacturing of die boards

Manufacturing of die boards
